TECHNICAL PARAMETER:
1.Dimension (mm):LxWxH :4000x2100x3250
2.Hopper: 1.5m3
3.Max flow: 3650 m?/h
4.Max vacuum degree: -80kpa
5.Rated vacuum degree:-60kpa
6.Vacuum pump working form: Constant volume Roots vacuum pump
7.Motor:55KW-75KW:380/220V:50Hz
8.Vacuum pump brand and model, original imported brand
9.Brand and Model of Electric Motor Nanyang
10.Maximum suction capacity: 350 kg/min
11.Maximum suetion distance (for coal ash):240m
12.Hopper: End discharge hopper
13.Unloading method: Air lift device+forklift unloading
14.Cleaning method: pulse cleaning
15.Cable storage cabinet with cable reel cabinet, with incoming cable of 15 meters and equipped with cablequick plug connector
16Trailer chassis is a 4-wheel trailer chassis that can be turned and driver
