FOG CANNON BY150

1. Spray Distance                     150m
2. Rated Power                        165kw
3. Fan Motor                            4Poles-132kw
4. Electronic                             Siemens PLC+Remote Control Schneider*ABB
5. Water Pump                         22Kw  CNP Brand,China
6. Water Consumption             18~25m³/h
7. Spray Head                           SS 304 Spray Nozzles, Total :180Pieces
8. Package Dimension              L4000*W2300*H2500mm
9. Gross Weight                        4200Kgs

Specification ：

No Item Technical Parameter   Remark
1 Spray Distance 150m
2 Rated Power 165kw
3 Fan Motor 4Poles-132kw   Hengli Brand
4 Motor Degree IP55
5 Fan Drum mm 1700mm
6 Control Cabinet Double Layer Carbon Steel
7 Electronic Siemens PLC+Remote Control Schneider*ABB
8 Water Pump 22Kw  CNP Brand,China
9 Water Consumption 18~25m³/h
10 Droplet Size 50-300μm
11 UP&Down Hydraulic Road
12 Protection Limit+Over Load+Water pump protection
13 Left&Right Hydraulic Gear Motor
14 Fan Blade Alu Alloy
15 Control On-site +100 m remote control
16 Pitching Angle -5--+30℃
17 Left*Right Angle 0-320℃
18 Spray Head SS 304 Spray Nozzles, Total :180Pieces
19 Thermal Protection With Electric Heating Optional
20 Package  Dimension L4000*W2300*H2500mm
21  Gross Weight 4200Kgs
22 Appearance Powder Painting As Per Client
23 Water Supply 4inch Pipeline,clean water 0.3Mpa～0.5Mpa
